Blue River
| Main particulars |
| Flag |
LIBERIA |
| Call Sign |
D5GZ5 |
| Year Built |
2002 |
| Shipyard |
TSUNEISHI SHIPBUILDING CO LTD. |
| Hull Number |
1233 |
| Classification |
DNV-GL |
| Class Notation |
1A1 , Tanker for oil, ESP, ED, LCS, VCS2 , NAUTICUS |
| IMO Number |
9247821 |
| Gross Tonnage |
57529 |
| Net Tonnage |
32149 |
| |
| Length overall |
240,50 |
| Length between perpendiculars |
230,00 |
| Breadth moulded |
42,00 |
| Depth |
21,20 |
| Draft summer (sw) |
14,85 |
| Deadweight at summer draft (sw) |
106638 |
| |
| Service speed (in ballast) |
14,80 |
| Service speed (laden) |
14,00 |
| |
| Fuel Oil consumption (main eng) |
47 MT/DAY @ FULL POWER/SPEED |
| Cruising range (nm) |
21900 |
| |
| Main Machinery |
| Main Engine |
MITSUI MAN B&W 6S60MC
MCR 12240 kW @ 105 RPM
NCR 11020 kW @ 101 RPM |
| Auxiliary Engines |
DAIHATSU 5DK-20 3 x 600 kW |
| Emergency generator |
MAN D 2866 TE 154 kW |
| Oil fired boilers |
MITSUBISHI MAC-55B 1 x 55000 KG/HR |
| Cargo Pumps |
| Cargo pumps |
STEAM TURBINE DRIVEN SHINKO KV400 3 x 2500 M3/HR |
| Stripping pumps |
STEAM DRIVEN SHINKO KPH200 1 x 200 M3/HR |
| Stripping eductor |
1 x 450 M3/HR |
| Ballast pumps |
ELECTRIC DRIVEN SHINKO CV450 1 x 3000 M3/HR |
| Ballast eductor |
1 x 300 M3/HR |
| |
| Deck Machinery |
| (type and brake holding capacity) |
| Windlass-mooring winch |
HYDRAULIC WINCH KAWASAKI 2 x 359 kN @ 9 M/MIN |
| Mooring winch forward |
HYDRAULIC WINCH KAWASAKI 2 x 147 kN @ 15 M/MIN |
| Mooring winch mid-deck |
HYDRAULIC WINCH KAWASAKI 1 x 147 kN @ 15 M/MIN |
| Mooring winch aft |
HYDRAULIC WINCH KAWASAKI 3 x 147 kN @ 15 M/MIN |
| |
| Cargo Oil Tanks |
| COMPARTMENT |
100% cub.metres |
98% cub.metres |
| No.1 COT (port and stbd) |
8302,20 |
8136,20 |
| No.2 COT (port and stbd) |
10041,10 |
9840,30 |
| No.3 COT (port and stbd) |
10090,00 |
9888,20 |
| No.4 COT (port and stbd) |
10090,00 |
9888,20 |
| No.5 COT (port and stbd) |
10090,00 |
9888,20 |
| No.6 COT (port and stbd) |
9737,60 |
9542,85 |
| Slop tank (port and stbd) |
2371,40 |
2323,97 |
| TOTAL |
121493,90 |
119064,02 |
| Other Tanks |
| COMPARTMENTS |
100% cub.metres |
98% cub.metres |
| Fuel tanks |
3416,70 |
3348,37 |
| Diesel Oil tanks |
278,70 |
273,13 |
| Lubricating oil tanks |
24,24 |
23,76 |
| Fresh water tanks |
358,40 |
351,23 |
| Drinking water tanks |
125,40 |
122,89 |
| Ballast water tanks total |
39420,30 |
38631,89 |
| Various other tanks |
126,90 |
124,36 |
|
|
 |
